| Material | 254 SMO, 316 STAINLESS STEEL, BRASS, Duplex 2205, Hastelloy® C-276, INCONEL, MONEL, SUPER DUPLEX 2507, TITANIUM |
|---|---|
| T - Tube O.D._mm | 10, 12, 14, 16, 18, 22, 25, 3, 4, 6, 8 |
| A_mm | 105, 55.1, 56.7, 58.7, 62.9, 64.1, 75.0, 75.4, 79.0, 86.0, 92.0 |
| B - Hex Flat_mm | 11.1, 12.7, 14.3, 15.9, 19.1, 22.2, 23.8, 25.4, 28.6, 31.8, 38.1 |
| C - Hex Flat_mm | 12.7, 14.3, 15.9, 17.5, 19.1, 23.8, 27.0, 30.0, 33.5, 40.0 |
| D_mm | 14.3, 15.1, 16.3, 16.7, 17.5, 22.2, 24.6, 25.0, 25.4, 27.0, 33.3 |
| E Min_mm | 12.7, 17.9, 2.3, 3.8, 5.8, 7.5, 11.9, 13.8, 18.1, 2.1, 9.1 |
| Fx_mm | 32.5, 34.6, 37.3, 41.1, 43.7, 48.0, 53.0, 60.0, 33.2, 36.6 |
| G_mm | 47.1, 48.9, 50.3, 54.9, 56.1, 63.0, 63.5, 68.0, 75.0, 81.0, 91.0 |
| J - Hex Flat_mm | 12.7, 15.9, 17.5, 19.1, 23.8, 27.0, 30.2, 33.3, 39.7, 14.3 |
| L_mm | 19.1, 15.9, 16.7, 17.3, 19.9, 24.5, 27.3, 28.2, 30.0, 35.4 |
| Panel Hole Size_mm | 11.5, 13.1, 16.5, 19.5, 22.5, 26.0, 29.5, 33.8, 8.3, 10.0 |
| Max. Panel Thickness_mm | 12.0, 13.0, 14.0, 16.0, 17.0, 24.0 |
Bulkhead Adapter: BA/MM
connects metric tube to metric port
Scarica il PDF tecnico
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Per poter scaricare i PDF deve essere registrato o fare login al nostro catalogo
Hoke, Gyrolok
