| Material | 254 SMO, 316 STAINLESS STEEL, BRASS, Duplex 2205, Hastelloy® C-276, INCONEL, MONEL, SUPER DUPLEX 2507, TITANIUM |
|---|---|
| T - Tube O.D. (in) | 1, 1/2, 1/4, 3/4, 3/8 |
| S - Straight Thread | 1 1/16-12, 1 5/16-12, 3/4-16, 7/16-20, 9/16-18 |
| A_in | 1.05, 1.19, 1.44, 1.59, 1.88 |
| B - Hex Flat_in | 11/16, 7/8, 9/16, 1 1/8, 1 7/8 |
| C - Wrench Pad_in | 1/2, 13/16, 1 1/8, 1 3/8, 5/8 |
| D_in | .64, .72, .97, 1.00, 1.31 |
| E Min_in | .19, .30, .42, .66, .88 |
| G_in | .78, .84, .97, 1.16, 1.31 |
| H_in | .39, .44, .66, 1/2 |
| H1_in | 1.05, 1.14, 1.30, 1.73, 1.86 |
| J - Hex Flat_in | 1 1/2, 1 1/4, 11/16, 7/8, 9/16 |
| W_in | .66, .80, 1.02, 1.44, 1.73 |
| O-ring Uniform Size Number | 904, 906, 908, 912, 916 |
45° Male Elbow, SAE, Positionable: LMFS
connects fractional tube to SAE straight thread boss
Scarica il PDF tecnico
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Per poter scaricare i PDF deve essere registrato o fare login al nostro catalogo
Hoke, Gyrolok
