| Tip | Hard, Soft |
|---|---|
| Weight_kg | 1.6 |
| Weight_Ib | 3.52 |
| Alloy | 316/316L, 6%Mo, 625 INCONEL®, 825 INCONEL®, Carbon Steel, Duplex, HASTELLOY® C276, MONEL®, Super Duplex, Titanium, Titanium Blue Anodized |
| Inlet Connection | Female, Integral GYROLOK, Integral Metric, Socket Weld |
| Inlet Size | 1/2" NPT, 1/2", 10 mm |
| Packing | GRAFOIL, PTFE |
Direct Mount 3-Valves Manifolds, Model-HM8312
Using the 3-valve manifold_x000d_
_x000d_
In normal operation the “isolate” valves are open while the “equalize” valve is closed._x000d_
_x000d_
This provides a differential pressure reading to the pressure gauge or transmitter. To zero the instrument, first close the downstream “isolate” valve then open the “equalize” valve and adjust the zero setting on the instrument._x000d_
_x000d_
Note: The body & trim parts on all 316/316L Valves & Manifolds comply to NACE MR-01-75 & NORSOK M-650 as standard.
