| Material | 254 SMO, 316 STAINLESS STEEL, BRASS, Duplex 2205, Hastelloy® C-276, INCONEL, MONEL, SUPER DUPLEX 2507, TITANIUM |
|---|---|
| P - Pipe Thread | 1/2, 1/4, 1/8, 3/8 |
| T - Tube O.D._mm | 10, 12, 14, 16, 18, 22, 25, 3, 6, 8 |
| A_mm | 48.0, 50.5, 54.2, 55.1, 55.2, 57.0, 59.0, 60.7, 66.0, 69.9, 70.7, 72.0, 76, 81.0, 88.0 |
| B - Hex Flat_mm | 11.1, 14.3, 15.9, 19.1, 22.2, 23.8, 25.4, 28.6, 31.8, 38.1 |
| C - Hex Flat_mm | 12.5, 15.9, 17.5, 19.1, 22.2, 23.8, 27.0, 30.0, 33.5, 40.0 |
| D_mm | 14.3, 16.3, 16.7, 17.5, 22.2, 24.6, 25.0, 25.4, 27.0, 33.3 |
| E Min_mm | 12.7, 2.2, 3.8, 5.8, 7.9, 9.9, 11.9, 6.6, 7.8 |
| Fx_mm | 32.5, 34.6, 37.3, 41.1, 43.7, 48.0, 53.0, 60.0, 36.6 |
| G_mm | 40.0, 42.2, 46.3, 46.8, 50.00, 51.1, 52.3, 54.1, 57.9, 59.0, 59.5, 64.0, 68.0, 73.0 |
| J - Hex Flat_mm | 12.7, 15.9, 17.5, 19.1, 23.8, 27.0, 30.2, 33.3, 39.7 |
| Panel Hole Size_mm | 11.5, 13.1, 16.5, 19.5, 22.5, 26.0, 29.5, 33.8, 8.3 |
| Max. Panel Thickness_mm | 12.0, 13.0, 14.0, 16.0, 17.0, 24.0 |
Bulkhead Connector, Male: BCM/ME
connects metric tube to female NPT threads
