| Material | 254 SMO, 316 STAINLESS STEEL, BRASS, Duplex 2205, Hastelloy® C-276, INCONEL, MONEL, SUPER DUPLEX 2507, TITANIUM |
|---|---|
| P - Pipe Thread | 1/2, 1/4, 1/8, 3/8 |
| T - Tube O.D. (in) | 1/2, 1/4, 3/8 |
| A_in | 1.05, 1.11, 1.19, 1.28, 1.44, 1.53 |
| B - Hex Flat_in | 11/16, 7/8, 9/16 |
| C_in | 0.625, 1/2, 13/16, 15/16 |
| D_in | .64, .72, .97 |
| E_in | .41, 0.19, 0.30, 0.42 |
| G_in | .72, .78, .84, .94, .97, 1.06 |
| H_in | .38, .56, .75 |
| H1_in | .78, .88, 1, 1.13, 1.38 |
45° Male Elbow: LMF
connects fractional tube to female NPT thread
Alternative O-ring materials are available, including silicone, and_x000d_
Buna-N.
Scarica il PDF tecnico
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Per poter scaricare i PDF deve essere registrato o fare login al nostro catalogo
Hoke, Gyrolok
